JT-7424 can package into wet inlay, standard card or the other heterotypic tags, achieving the needs of industry, and application.
It is convenient to stick with the characteristics that are widely applied to aviation, warehousing, retail, clothing, medical, anti-counterfeiting and other fields.
JT-7424 can package into wet inlay, standard card or the other heterotypic tags, achieving the needs of industry, and application.
It is convenient to stick with the characteristics that are widely applied to aviation, warehousing, retail, clothing, medical, anti-counterfeiting and other fields.
Our excellent R&D team can customize the design of high-performance tag antenna with special specification.
|
· Basic parameters |
|
|
Model |
JT-7424 |
|
Type |
UHF passive RFID tags |
|
Frequency |
860~960MHz |
|
Standards/Protocols |
EPC CLASS1 GEN2, ISO 18000-6C |
|
· Physical parameters |
|
|
Size |
74*23mm=2.91*0.9inch(Customized Design) |
|
Inlay Material |
PET+AL |
|
Outer Material |
Copper paper / PET / PVC /Thermal paper |
|
· Performance Parameters |
|
|
Memory Size |
Up to 512bit |
|
Chip |
Impinj M5/Alien H3 /Alien H4 |
|
Operating Mode |
R/W |
|
Reading Distance |
8M(Related to reader performance and working environment) |
|
· Environmental parameters |
|
|
Operating Temp |
-20℃~+50℃ |
|
Storage Temp |
-40℃~+100℃ |
|
· Specific applications |
|
|
Applications |
Aviation, logistics, warehousing, retail, clothing, medical, anti-counterfeiting etc. |
|
· Packaging and delivery |
|
|
Package |
2000pcs/roll |
