Feature:
Support ISO18000-6C Gen 2 protocol;
Stable reading to 25m(with external 12dbi antenna, Alien H3 9662 tag)
Excellent ability of reading and writing, better to prevent collision;
Support multiple frequency standard
Good heat dissipation effect to ensure the stability of equipment
|
Item No. |
JT-918B |
|
Performance parameters |
|
|
Working Frequency |
902~928 MHz or 865~868MHz |
|
Protocol |
ISO18000-6C(EPC C1 GEN2) |
|
Output power |
15~30dBm(Adjustable) |
|
Reading Range |
With white card & 12dBi antenna, 30m |
|
RF port |
Four-way SMA-Female |
|
Communication Protocol |
Asynchronous serial port |
|
UART port |
Baud Rate 115200, TTL |
|
USB port |
One-way USB2.0 all speed port |
|
Current rating |
Max 1A |
|
Standby current |
<60mA |
|
Physical parameters: |
|
|
Item size |
150x120MM |
|
Net weight |
12g |
|
Working temperature |
-20℃~+50℃ |
|
Storage temperature |
-30℃~+75℃ |
|
Operating power |
DC3.7V~5V |
